Description
DIMENSIONS (L x W x H)
- EXTERNAL (MM) – 6058 x 2438 x 2591
- EXTERNAL (FT) – 20’ x 8’ x 8’6”
- INTERNAL (MM) – 5450 x 2294 x 2164
- INTERNAL (FT) – 17’11” x 7’6” x 7’1”
WEIGHT
- TARE – 5270 KGS / 11618 LBS
- PAYLOAD – 14730 KGS / 32474 LBS
- MAX GROSS WEIGHT (MGW) – 20000 KGS / 44092 LBS
ADDITIONAL FEATURES
- Designed, Constructed, Tested to EN12079-1 / DNV 2.7-1 / SEPCo OPS 0055 / API RP
