Description
DIMENSIONS L X W X H
- EXTERNAL (MM) – 2422 x 1584 x 1912
- EXTERNAL (FT) – 7’11” x 5’2” x 6’3”
WEIGHT
- TARE – 1460 KGS / 3220 LBS
- PAYLOAD – 2900 KGS / 6390 LBS
- MAX GROSS WEIGHT (MGW) – 4360 KGS / 9610 LBS
CAPACITY
- VOLUME – 2082 L / 550 GALS
FRAME
- Designed, Constructed, Tested to EN12079-1 / DNV 2.7-1
- Steel Tubing Frame, Stackable and Forklift Pockets on all Four Sides
VESSEL
- UN/DOT Certified (31H2)
- Packaging Group II & III per Title 49 CFR
- 1/2” Rotationally Molded Polyethylene
- 1/2” Wall Thickness, HDPE Linear
- 1.9 Specific Gravity
- Two 2” Bungs, One in Tank Top and One in Tank Lid
- 2” Plastic Vacuum Relief Vent
- 6.5” Heavy-Duty Fill Cap with Tether
- 2” Full Port Bottom Drain Valve with Dust Cap
- Molded-in and Inked Gallon Marker
