Description
DIMENSIONS (L x W x H)
- EXTERNAL (MM) – 12192 x 1219 x 686
- EXTERNAL (FT) – 40’ x 4’ x 2’2”
- INTERNAL (MM) – 11989 x 1016 x 432
- INTERNAL (FT) – 39’4” x 3’3” x 1’4”
WEIGHT
- TARE – 2800 kgs / 6170 lbs
- PAYLOAD – 10000 kgs / 22050 lbs
- MAX GROSS WEIGHT (MGW) – 12800 kbs / 28220 lbs
ADDITIONAL FEATURES
- Designed, Constructed, Tested to EN12079-1 / DNV 2.7-1 / SEPCo OPS 0055 / API RP
